READ MORERecommendations for the use of polyimide film tapes
Polyimide film tape is widely used in electronics, aerospace, industry and medical fields due to its excellent high temperature resistance, chemical resistance and electrical insulation. The correct method of use is essential to ensure its performance and extend its service life.
Choosing the right polyimide film tapes
Application environment analysis: When choosing polyimide film tape, the application environment should be considered first. For example, for high temperature environments (such as welding protection of electronic components), it is necessary to choose a tape with high temperature resistance; for occasions requiring electrical insulation, products with excellent electrical insulation properties should be selected.
Tape thickness: The thickness of polyimide film tape affects its mechanical strength and temperature resistance. Thicker tapes provide better protection, but may affect flexibility. When choosing thickness, it is necessary to balance the protection performance and actual application requirements.
Adhesion: Different application scenarios require different adhesion of the tape. Choose the right adhesion to ensure that the tape can be firmly attached to the substrate, and will not leave residual adhesive or damage the substrate when removed.
Surface treatment
Substrate cleaning: Before applying polyimide film tape, make sure the surface is clean, dry and free of grease. Use an appropriate cleaner or solvent (such as isopropyl alcohol) to remove dust, oil or other contaminants on the surface to ensure that the tape can adhere fully.
Surface finish: For substrates with uneven surfaces or burrs, it is recommended to first perform surface treatment or polishing to improve the adhesion of the tape. Rough surfaces may cause uneven adhesion or peeling of the tape.
Application technology
Temperature and humidity control: When applying polyimide film tape, make sure that the ambient temperature and humidity are within the recommended range. Too high or too low temperature and humidity may affect the adhesion performance and stability of the tape. The recommended ambient temperature is generally 15°C to 25°C, and the humidity should be between 40% and 60%.
Uniform pressure: When applying the tape, make sure to apply uniform pressure to help the tape better contact with the substrate. Using a roller or special tool can help flatten the tape and remove air bubbles to improve adhesion.
Cutting and trimming: Use a sharp knife or scissors to cut the tape, and avoid tearing or damaging the edge of the tape. Precise cutting can ensure that the edge of the tape is neat, improving aesthetics and functionality.
Special applications
Applications in electronic equipment: When using polyimide film tape in electronic equipment, ensure that it has good electrical insulation properties and can withstand temperature fluctuations during equipment operation. For circuit board protection, tapes with high insulation strength should be selected, and ensure that they are firmly adhered to prevent them from falling off during use.
High temperature protection: In high-temperature welding or heat treatment processes, the use of polyimide film tape can effectively prevent heat damage to the substrate. Select tapes with superior high temperature resistance and avoid exceeding their rated temperature range in actual applications.
As a high-performance material, polyimide film tape plays an important role in many fields. Through precise selection, scientific construction methods and perfect after-sales service support, its advantages can be fully utilized to provide strong guarantees for the development of various industries. With its deep industry accumulation and technical strength, Wuxi Wanfeng Protective Film Co., Ltd. will continue to provide customers with high-quality tape products and professional solutions.
